Materials：Tool Steel

Doubleshear beam.

Strong yaw stiffness and retortion capability.

Sensitivity	3±0.01mv/v
Nonlinearity	±0.03%FS
Hysterasis	±0.03%FS
Repeatablility	0.02%FS
Creep	±0.03%FS/30min
Zero balance	2%FS
Zero output temperature coefficient	±0.03%FS/10℃
Reated output temperature coefficient	±0.03%FS/10℃
Output resistance	700Ω
Insulation resistance	≥5000MΩ
Supply Voltage	5～15V
Temperature compensation range	-10～+50℃
Safe temperature range	-30～+60℃
Safe overload	130%FS
Method of connecting wire	输入input：红Red(+)黄Yellow(-) 输出output：兰Blue(+)白White(-)
