Materials：Tool Steel

Wide range ability, high precision, stable properly,can be widely used in electronic automobile weighing apparatus, hopper scale, tank scale,

Secong Generation of cs-16, little influence under heat expansion and cooling shrinkage.

Sensitivity	2±0.01mv/v
Nonlinearity	±0.02%FS
Hysteresis	±0.02%FS
Repeatability	0.01%FS
Creep	±0.02%FS/30min
Zero balance	2%FS
Zero temperature coefficient	±0.02%FS/10℃
Rated output temperature coefficient	±0.02%FS/10℃
Ouput resistance	350Ω
Insulation resistance	≥5000MΩ
Supply voltage	5～15V
Temperature compensation range	-10～+50℃
Safe temperature range	-30～+60℃
Safe overload	130%FS
Method of connecting wire	输入input：红Red(+)黄Yellow(-) 输出output：兰Blue(+)白White(-)
