Materials：Tool Steel 　Stainless steel

Lmitate Philips PR6201.

Widely used in railroad track scale and hopper scale.

Sensitivity	1.0±0.01mv/v      1.5±0.01mv/v
Nonlinearity	±0.02%FS
Hysteresis	±0.02%FS
Repeatability	0.01%FS
Creep	±0.02%FS/30min
Zero balance	2%FS
Zero temperature coefficient	±0.02%FS/10℃
Rated output temperature coefficient	±0.02%FS/10℃
Input resistance	675±5Ω
Output resistance	600Ω
Insulationg rasistance	≥5000MΩ
Supply Voltage	5～15V
Temperature compensation range	-10～+50℃
Safe temperature range	-30～+60℃
Safe overload	130%FS
Method of connecting wire	输入input：红Red(+)黄Yellow(-) 输出output：兰Blue(+)白White(-)
