APPLICATION RANGE
Electronic platform scale, levertronic scale, electronic floor scale and static weighing system equipped with 1-4 load ceils.
(AI applicable to weighing system with 1 load cell)

BASIC FUNCTION
Adjusting & calibrating on keyboard / parameter setup
Seff-checking and multi-information indication
Tare and preset tare value
Real-time clock / calender display
Manual storing and accumulating weighing records
Storing weighing records and power-off protection
Automatic / manual printing weighing records

MAIN TECHNICAL PARAMETER
Load cell output sensitivity:1 ~3mV/V
Power supply:AC 187~242V; 49~51Hz
Display:7-bit LED, 7-status indication
Communication interface:RS232 baud and mode optional
Scoreboard intetface:serial output transmission distance:≤50m
Prlntlng Intervace:parallel
Ambient temperature:0-40℃
Ambient humidity:≤85%RH

RECOMMENDATION OF MODIFIED TYPE
Modified type with peak-holding function
